Specification
| I T E M S | S P E C I F I C A T I O N |
| Wave Lengths | 185 to 260nm(UV) / 4.35um(IR) |
| Detection Distance | n-Heptane(30m) |
| Field of View | 100° max. conical |
| Sensitivity Range | 4 mode: Low, Normal, Medium, High (Dip switch selectable) |
| Typical Response Time | < 3sec @ 30m(n-Heptane) |
| Minimum Sensor Response Time | 500 ms |
| Alarm Delay Time | 1, 3, 5, 7 secs (Dip switch Selectable) |
| Typical Alarm | Alarm LED & Relays : Latching / Non-Latching |
| (Dip switch Selectable) | |
| Approval | Ex dⅡC T4,T5,T6 |
| Temperature Range | T6=-50˚C to +60˚C, T5=-50˚C to +75˚C, T4=-50˚C to +85˚C |
| Humidity Range | 0 to 100% RH, non-condensing |
| Status Indicator | 4 – 20mA DC / RS-485 Modbus / Alarm LED / Power LED |
| RS-485 Output (Option) | Modbus Protocol Address : 1 to 128 (Dip switch Selectable) |
| Relay Output | 2SPDT Relay contact (3A at 30Vdc or 5A at 250Vac) Alarm, Fault |
| Open collector Output | +24V signal output |
| Normal status : Vin(Normally +24Vdc), Alarm status: 0V | |
| Operating Voltage | Standard : 18 ~31V DC (24V DC normal) / 40mA Max. |
| 18 ~31V DC (24V DC normal) / 280mA Max. | |
| Power Consumption | |
| 전선연결 | Standard type : (CVVS or CVVSB 1.5sq↑)+Shield |
| (Signal Cable CONnectiON) | PoE type : RJ45 Ethernet Cable |
| Cable Connection Length | 4 – 20mA DC Signal : 2000m |
| RS-485 Modbus Signal : 1000m | |
| Conduct Connection | 1/2″ PF, NPT(1/2″ PF 기본사양) |
| Weight | Standard type : 0.7 kg |
| Dimensions | Standard type : 76(W) × 76(H) × 96.5(D) mm |
